We have been the best trader and manufacturer
of Stainless Steel products in Korea since 1982.
Our Ulsan Plant has been equipped with the biggest
Surface-polishing line in Korea with the annual
capacity of 50,000 M/T. We are very proud of our
long experience, profound knowledge and the excellent
competitiveness in this field. |
|
|
Under the remarkable name of SAMMI with excellent quality,
we have been keeping up good business relationship with
many companies from the entire world.
We assure that we will make full efforts to meet requirements
and satisfaction from customers.
|
| |
|
|
- Stainless Steel Flat Products
- Stainless Steel Long Products (Pipe/Tube/Wire/Bar)
- Specialty Steel Flat/Long Products
- Coated Steel (Galvalume/GI/EGI/Tin Plate)
- Semi Finished Products
|
|
| |
|
|
| |
|
|
Items & Manufacturing
Range
|
|
Grade
|
301(L), 304(L), 304J1,
316(L), 321
409L,410, 420J1(J2), 430, 430J1L(CuN), 434
436L, 444, 445M2
|
|
Surface Finish
|
2D, 2B
|
BA, BB, BD
|
EM, #4, HL
|
HD
|
#8
|
1D
|
|
Thickness
(§®)
|
0.25~5.0
|
0.1~2.0
|
0.4~2.0
|
0.05~5.0
|
0.6~2.0
|
2.0~7.0
|
|
Width(§®)
|
17~1250
|
17~1219
|
17~1250
|
17~1250
|
1000~1250
|
1000~1524
|
|
Length (Coil&Sheet)
|
In Coil : 3~5 M/T, 4~6
M/T, In Sheet : Max. 8,000mm
|
|
| |
|
|
|
| |
|
|
| |
|
Machines
|
Specification
|
|
Thickness
(mm)
|
Width (mm)
|
Length (mm)
|
Length Allowance
|
Diagonal Allowance
|
Unit Weight
|
CAPA (MT/month)
|
|
HR SHEARING
|
2.0 ~ 7.0
|
1550
|
1,000 ~ 8,000
|
+/-0.5
|
+/-0.5
|
16 M/T
|
30,000/1SH
|
|
CR SHEARING
|
0.25 ~ 2.5
|
300 ~1,280
|
500 ~ 4,000
|
+/-0.5
|
+/-0.5
|
20 M/T
|
24,000/1SH
|
|
SHEARING & COILING
|
0.3 ~ 2.0
|
600 ~1,280
|
500 ~ 6,000
COIL
|
+/-0.5
|
+/-0.5
|
16 M/T
|
18,000/1SH
|
|
COIL POLISHING
|
0.4 ~ 2.0
|
600 ~1,280
|
COIL
|
|
|
16 M/T
|
24,000/2SH
|
|
CR SLITTER
|
0.25 ~ 2.5
|
30 ~1,550
|
COIL
|
|
|
20 M/T
|
30,000/1SH
|
|
| |
|
|
| |
1. Grade : 300 series & 400 series
(to be discussed)
2. Spec. : KS D3698, AISI, ASTM A240/480,
JIS G4305, EN 10088-2 - 17441 etc
3. Surface Finish : 1D, 2D, 2B, BD, BB, BA,
No.4, No.8, HL, HD, Embossing with various pattern,
etc |
|
| |
|
|
KS
D3698
|
JIS
G4305
|
ASTM
A480
|
EN
10088-2
|
Finishing Processes
|
|
1D
|
-
|
No. 1
|
No. 1
|
1D
|
Hot-rolled, annealed, and descaled |
|
2D
|
No. 2D
|
No. 2D
|
No. 2D
|
2D
|
Cold-rolled, annealed/pickled |
|
2B
|
No. 2B
|
No. 2B
|
No. 2B
|
2B
|
Cold-rolled, annealed/pickled, skin passed |
|
BD
|
-
|
-
|
-
|
-
|
Cold-rolled, bright-annealed |
|
BB
|
-
|
-
|
-
|
-
|
Cold-rolled, bright-annealed, light skin pass |
|
BA
|
BA
|
BA
|
Bright
Annealed
|
2R
|
Cold-rolled, bright-annealed, heavy skin pass |
|
#4
|
No. 4
|
No. 4
|
No. 4
|
2J
|
Surface polished with 150~180mesh abrasives |
|
#8
|
-
|
-
|
No. 7
|
2P
|
Buffed surface with fine 800mesh abrasives |
|
HL
|
HL
|
HL
|
-
|
2M
|
Surface with continuous stripped pattern by grit |
|
HD
|
-
|
-
|
TR
|
2H
|
Cold-rolled to obtain specified physical properties |
|
| |
Hot-Rolled Stainless Steel |
| Hot-Rolled Stainless Steel is produced by hot-rolling
slab in 1200¢ªC and pickling. Main usage is Tank,
Plant, Tube and other industrial materials. It is
mainly used in high corrosion-resisting product
rather than in the high quality surface product |
| |
|
Cold-Rolled Stainless Steel |
| Cold-Rolled Stainless Steel is produced by rolling
the hot-rolled coil in the normal temperature and
by pickling & annealing. Second surface processing
can produce various beautiful surface products.
It is mainly used in various applications like facing
building. |
| |
| |
| 4. Thickness |
- Unless otherwise specified, thickness
follows minus side of each spec.
- Thickness is measured
at an arbitrary point which is more than 25mm
inward from the edge in the case of mill edge
and more than 15mm inward from the edge in
the case of slit edge. This is not applicable
to unstable parts at the start and the end
of rolling. |
|
| |
| 5. Width(Slit Edge) : 1000mm/1219mm/1250mm
|
| |
| 6. Length : in the case of sheet - 2000mm/2438mm/2500mm
up to 8000mm |
| |
| 7. Packing : Mill's export
standard packing |
- With Paper interleaving (Protect coating
film is available upon request.)
- Coil: 3~5mt/ 4~6mt
- Coil ID : 508mm
- Sheet: 1~2mt |
|
| |
| 8. Payment : |
| By ire. L/C at sight in our favor or T/T
30% of total amount with order confirmation
and balance should be remitted against fax
copy of invoice and packing list prior to
shipment |
|
| |
| 9. Shipment : within 40days after receipt
of L/C |
| |
| 10. Inspection : Mill's one to be final
(Mill's inspection certificate) |
| |
|
| |
| |
 |
 |
